ZARA Wall Hung Rimless In Wall Toilet Suite Pan
The ZARA Wall Hung Rimless In-Wall Toilet Suite Pan combines a sleek floating design with hygienic rimless technology and water-efficient dual flushing. Its compact 515mm projection makes it well suited to modern bathrooms, while compatibility with multiple concealed cistern systems provides flexibility during installation.
Key Features & Benefits
- Wall-Hung Design – Creates a clean, floating appearance while keeping the floor underneath open and easy to clean.
- Hygienic Rimless Plus Technology – Features a smooth, rimless bowl designed for easier cleaning and maintenance.
- Compact 515mm Projection – An excellent space-saving option for bathrooms and ensuites.
- Gloss White Finish – Provides a clean, timeless appearance that complements a wide range of bathroom styles.
- High-Quality Vitreous China – Durable ceramic construction designed for long-term everyday use.
- Slim Soft-Close Seat – Includes an easy-release, heavy-duty slim seat for smooth and quiet operation.
- R&T Dual-Flush Technology – Provides efficient 4.5L/3L flushing.
- P-Trap Installation – Designed for a 180mm P-trap configuration.
- Multiple Cistern Options – Compatible with Geberit Duofix and R&T framed in-wall cistern systems.
- 20-Year Ceramic Product Warranty – Includes 1 year of parts and labour coverage.
Specifications
| Specification | Details |
|---|---|
| Product | ZARA Wall Hung Rimless In-Wall Toilet Suite Pan |
| Model | ZAWH |
| Toilet Type | Wall-Hung Pan |
| Dimensions | 515 × 355 × 365mm |
| Pan Height from Base | 365mm |
| Material | Highest Quality Vitreous China |
| Colour | Gloss White |
| Flush Technology | R&T Dual-Flush |
| Bowl Design | Rimless |
| Seat | Heavy-Duty Slim Soft-Close |
| Trap Type | P-Trap |
| P-Trap | P180 |
| P-Trap Connection | 180mm |
| Full Flush | 4.5L |
| Reduced Flush | 3L |
| WELS Rating | 4 Star |
| WELS Licence | 1743 |
| Product Warranty | 20 Years |
| Parts & Labour Warranty | 1 Year |
Hygienic Rimless Design
The ZARA incorporates Hygienic Rimless Plus Technology, eliminating the traditional concealed rim around the bowl. This creates fewer hard-to-reach areas where residue can accumulate and makes the toilet surface easier to clean.
The smooth gloss white vitreous china finish further complements the hygienic, low-maintenance design.
Compact Wall-Hung Installation
With a 515mm projection, the ZARA is designed to maximise usable bathroom space. Its wall-hung configuration keeps the floor beneath the pan clear, creating a visually open bathroom and making routine floor cleaning easier.
The pan uses a P180 P-trap with a 180mm connection, providing a straightforward concealed waste configuration.
Flexible In-Wall Cistern Options
The ZARA can be paired with several concealed cistern systems:
- Geberit Duofix Sigma 8 In-Wall Cistern
- Geberit Duofix Kappa Under Counter In-Wall Cistern
- R&T Framed In-Wall Cistern
This flexibility allows the concealed cistern to be selected according to the installation requirements and project specification.
Water-Efficient Dual Flush
The R&T dual-flush system provides a 4.5L full flush and 3L reduced flush. With a WELS 4-star rating and WELS licence number 1743, the ZARA provides an efficient solution for everyday bathroom use.
The ZARA Wall Hung Rimless In-Wall Toilet Suite Pan is an ideal choice for contemporary bathrooms seeking a compact floating design, hygienic rimless bowl, gloss white vitreous china, soft-close seating and water-efficient 4.5L/3L flushing.
