Zeus Tornado Rimless Wall Faced Floor Pan

The Zeus Tornado Rimless Wall Faced Floor Pan combines a contemporary wall-faced design with efficient Tornado rimless flushing and an easy-height profile. With a compact 585mm projection, 4.5L/3L dual-flush system and multiple trap options, it provides a versatile solution for modern bathroom installations.

Key Features & Benefits

• Tornado Rimless Flush – Designed to provide effective bowl cleaning while reducing hard-to-reach areas.
• Wall-Faced Floor Pan – Sits neatly against the wall for a clean, streamlined bathroom appearance.
• Easy Height Design – The raised 455mm height provides a comfortable seating position.
• 4.5L/3L Dual Flush – Offers full and reduced flush options for efficient water consumption.
• Compact Design – Measures 585 × 360 × 455mm, making it suitable for a variety of bathroom layouts.
• UF Slim Soft-Close Seat Included – Supplied with SC1064.
• Trap-100 Included – Supports a 100–150mm offset range.
• Flexible Trap Options – Additional S-trap and P-trap configurations are available separately.
• Comprehensive Warranty – Includes separate coverage for ceramic components, parts and inlet/outlet valves.

Specifications

Rimless Tornado Flushing

The rimless Tornado design provides a streamlined bowl with fewer concealed areas where residue can accumulate. The flushing system is designed to distribute water effectively around the pan, helping maintain bowl cleanliness while making routine cleaning easier.

Easy-Height Comfort

With an overall height of 455mm, the Zeus provides a raised seating position designed for increased comfort. Its wall-faced configuration keeps the pan close to the wall, creating a neat and uncluttered appearance.

Flexible Trap Configuration

The supplied Trap-100 accommodates a 100–150mm offset. For alternative plumbing configurations, the following traps are available separately:

• Trap-60: 60–90mm
• JT43: 150–185mm
• P-Trap K212: 180mm

This range of options provides additional flexibility when connecting the toilet to different existing waste outlet positions.

Warranty

• 10-year replacement warranty on ceramic components, including pans and cisterns.
• 1-year replacement warranty on parts, including toilet seat covers, flush pipes and buttons.
• 3-year replacement warranty on inlet and outlet valves.
• Terms and conditions apply.

The Zeus Tornado Rimless Wall Faced Floor Pan is an excellent choice for contemporary bathrooms seeking easy-height comfort, efficient 4.5L/3L dual flushing, rimless Tornado technology and flexible installation options.
